BP52 Wired Alarm Panel

Call for Price

SKU: BP52

Call to Order

10 years

Free UPS Ground Shipping 2-5 days

Download Data Sheet (PDF)

Description

Enterprise wired alarm panel with 32 zones, 4 RS485 outputs, and 4 PoE+ ports — the central brain of a Verkada wired alarm system. Replaces traditional panels while retaining existing wired sensors and devices. Supports conventional and addressable fire inputs (IDC/SLC), wireless sensors via VLink, and integrates natively with Verkada cameras for video-verified alarms. Cloud-managed via Verkada Command. 10-year hardware warranty.

Specifications

Network & integration

Alarm inputs32 zones with 12V DC aux power

Power & installation

Dimensions21.9" H × 12.7" W × 4.6" D

Power input100-240V AC (50-60Hz)

Environment & compliance

Warranty10 years

Other specifications

WirelessVLink sub-GHz transceiver

PoE outputs4x PoE+ / 802.3at (60W total)

RS485 outputs4x with 36V DC aux power

Documentation

Datasheet — BP52-alarm-panel-datasheet.pdf

Ships from our Hollywood, FL warehouse with free UPS Ground shipping within the US. 30-day returns per our Return Policy. Need help sizing a system or checking compatibility? Call (954) 903-0007.
