poe16 × RJ45 PoE — 30 W/port, 240 W total (IEEE 802.3at / 802.3af)
vcaFace detection & comparison, SIP 2-ch, UMD 4-ch, people counting, traffic monitoring, auto tracking
sata2 × SATA, up to 10 TB each
audio1-ch RCA in / 1-ch RCA out, two-way audio — G.711A / G.711U
onvifONVIF Profile S / G / T + RTSP
powerAC 100–240 V, ≤ 12 W (without HDD)
alarms8 alarm in / 2 alarm out — motion, tampering, video loss, defocus, object left/removed, audio
weight≤ 2.7 kg (without HDD)
network1 × GbE LAN; USB 3.0 (rear) + USB 2.0 (front); RS485
decodingSmart off: 2 × 12MP@30, 2 × 4K@30, 4 × 4MP@30, 10 × 1080p@30, 16 × 720p@30 — Smart on: 2 × 4K@30, 4 × 4MP@30, 8 × 1080p@30, 16 × 720p@30
vcaSearchFace snapshot, face comparison, vehicle (motor / non-motor), human body, heat map, AcuSearch
vgaOutputUp to 1920 × 1080p @ 60 Hz
dimensions380 × 322 × 53 mm (1.5U)
hdmiOutputUp to 3840 × 2160 @ 30 Hz (4K)
compressionUltra 265 / H.265 / H.264
environment−10 °C ~ +55 °C, ≤ 90% RH (non-condensing)
remoteUsers128
ipVideoInput16-ch
certificationCE / FCC / UL / RoHS / WEEE
vehicleLibraryUp to 5 libraries / 25,000 vehicle pictures
incomingBandwidth160 Mbps
outgoingBandwidth128 Mbps
recordingResolution12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
