poe8 × RJ45 PoE — 30 W/port, 75 W total (IEEE 802.3at / 802.3af)
vcaSIP + UMD on all 8 channels; intrusion, cross line, enter/leave area, object left/removed, scene change, defocus
sata1 × SATA, up to 8 TB
audio1-ch RCA in / 1-ch RCA out — G.711A / G.711U
onvifONVIF Profile S / G / T + RTSP
power52 V DC, ≤ 8 W (without HDD)
alarmsMotion, tampering, human body, video loss, audio detection
alertsIP conflict, disk abnormal, illegal access, disk full
weight≤ 1 kg (without HDD)
network1 × RJ45 10/100 self-adaptive; USB 3.0 + USB 2.0
decoding2 × 4K@30, 3 × 5MP@30, 4 × 4MP@30, 5 × 3MP@30, 8 × 1080p@30
vcaSearchBehavior search; people counting (flow + crowd density)
vgaOutputUp to 1920 × 1080p @ 60 Hz
dimensions260 × 240 × 47 mm (1U)
hdmiOutputUp to 3840 × 2160 @ 30 Hz (4K)
compressionUltra 265 / H.265 / H.264
environment−10 °C ~ +55 °C, ≤ 90% RH (non-condensing)
remoteUsers128
ipVideoInput8-ch
incomingBandwidth80 Mbps
outgoingBandwidth64 Mbps
recordingResolution4K / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
