MAC8K
ClassDate | Title | Type | Download
Weight<4.2 kg
HD Image2026/8/24 10:26:55 | NSW2010-18GT2GP-POE-IN_HD_Image_1.png | png | Download
PoE ModeModeA (1236)
Datasheet2025/6/20 11:37:30 | UNV NSW2010-18GT2GP-POE-IN Gigabit Ethernet Switches.pdf | English | pdf | Preview | Download
IndicatorPWR: Steady on: AC input is normal Off: No AC input PoE: Off: No PoE power supply Steady on: PoE power supply is normal Flashing: PoE power supply is abnormal LINK/ACT: Off: No link Flashing: Transmitting data
Max.Power200W
StandardsIEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at
Ports Type16×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)+2×1000Mbps ports（SFP）
Cooling Fans1
PoE StandardIEEE 802.3af, IEEE 802.3 at
Power SupplyAC: 100 to 240V, 50/60Hz
Working ModeDefault (Normal mode) : All ports can communicate with each other, VLAN (Secure mode): Downlink ports can communicate only with uplink ports., Extend (Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports
Max.PoE Power185W
Packet Buffer4 M bit
Operating Humidity10% to 90% (noncondensing)
Switching capacity40 Gbps
Dimensions (W×D×H)280mm x 180mm x 44mm (11"×7.1"×1.7")
Operating Temperature0°C to 40°C (32°F to 104°F)
Forwarding performance29.76Mpps
