aclYes
arpYes
bgpYes
cpuQuad-core processor, 1.8 GHz clock frequency per core
dnsYes
emcFCC Part 15B
fanFanless design
natYes
ntpNTP client
pbrIPv4 and IPv6 PBR
ram4 GB
ripYes
sshNo
stpNo
ddnsYes
dhcpYes
emmc8 GB
iptvYes
leds1 x system status LED 10 x Ethernet port LEDs 1 x HDD LED
lldpNo
ospfYes
rldpNo
rlogYes
snmpYes
upnpYes
vlanYes
vrrpNo
is isNo
screw8 X M4 x 8 mm cross recessed countersunk head screws-
device1
sd wanYes
syslogYes
telnetNo
weight3.82 kg (8.42 lbs) (with packaging materials) 3 kg (6.61 lbs) (without packaging materials)
buttons1 x reset button
coolingNatural cooling
stackingNo
warranty3 years
audit logYes
hard disk1 x standard SATA 3.0 HDDs
ipv4 ipv6Yes
multicastNo
proxy arpNo
http loginYes
power cord1 x 1.8 m (70.86 in.)31.49 in. x 1 pieces
rubber pad4
throughput4000 Mbps
https loginYes
user manual1
flash memory128 MB
flow controlYes
mab on cloudYes
power method220 V AC power supply: Voltage: 100 V AC to 240 V AC Frequency: 50 Hz to 60 Hz Rated input current: 1.5 A
working modeAC mode Routing mode
ap managementWi-Fi RF parameters Managing clients Configuring an allowlist and a blocklist 802.1X authentication AP Mesh WQoS 802.11k/v roaming AP portal authentication AP load balancing AP LEDs Layer 2 isolation Configuring the power supply mode of the AP on Cloud
certificationFCC, IC, cTUVus
dhcp snoopingNo
file transferNo
mounting typeDesktop Mounting
security zoneYes
traffic auditYes
warranty card1
esd protectionContact discharge: 6 kV Air discharge: 8 kV
ip mac bindingYes
load balancingYes
ndaa compliantYes
static routingIPv4 and IPv6 Static route
web managementYes
fault diagnosisYes
cloud managementUpgrading device software version through App Restarting devices through App Remotely monitoring devices through App Self organizing network through code scanning Cloud-based O&M Cloud-based upgrade
site to site vpnIPsec VPN WireGuard
storage humidity5% RH to 95% RH (non-condensing)
surge protectionService port: ±6 kV for common mode Power connector: ±6 kV for common mode and ±6 kV for differential mode
management on appYes
openvpn bandwidth300 Mbps
safety complianceUL 62368-1
url based routingYes
client associationYes
client to site vpnL2TP VPN L2TP over IPSec VPN OpenVPN PPTP VPN WireGuard
enclosure materialMetal
l2tp vpn bandwidth1150 Mbps
operating humidity10% RH to 90% RH (non-condensing)
pptp vpn bandwidth1450 Mbps
product dimensions440 mm x 210 mm x 43.6 mm (15.75 in. x 8.27 in. x 1.72 in.)
rack mount bracket2
sd wan performance1200 Mbps
application controlYes
ipsec vpn bandwidth730 Mbps
storage temperature–40°C to +70°C (–40°F to +158°F)
fan speed adjustmentNo
fault self diagnosisYes
internet access modePPPoE DHCP Static IP
local attack defenseYes
multicast rate limitNo
number of bgp routes10000
number of rip routes1000
pppoe authenticationYes
802 1x authenticationYes
mac address filteringYes
max power consumption18 W
operating temperature0°C to 40°C (32°F to 104°F)
web login informationYes
wireguard performance1200 Mbps
self organizing netowkYes
maximum number of ssids8
number of lan wan ports8
number of ospfv3 routes10000
ipv6 ipsec vpn bandwidth900 Mbps
number of 10ge sfp ports2
l2tp over ipsec bandwidth750 Mbps
number of fixed lan ports1
number of fixed wan ports1
power cord retention clip1
maximum number of lan port9
network sharing preventionYes
number of ipv4 pbr entries30
number of ipv6 pbr entries30
number of ospfv2 instances16
third party authenticationWISPr for third-party portal authentication Wi-FiDog for third-party portal authentication
total number of rj45 ports8
cloud portal authenticationCustom portal page Delivery through cloud portal page One-click login to cloud portal page Account-based authentication Voucher authentication SMS-based authentication supported by cloud portal page
local portal authenticationSMS-based authentication One-click authentication Authorization-based authentication QR code authentication Authentication (IP address-based) across Layer 3 switches Self-service logout
maximum number of wan ports9
mab for local authenticationYes
user behavior management ubmYes
maximum number of aps ac mode1000
maximum number of arp entries4096
number of dynamic ipv4 routes1000
number of dynamic ipv6 routes1000
total number of optical ports2
number of port mapping entries512
number of 10 100 1000base t ports4
limiting the number of connectionsYes
maximum number of aps routing mode1000
local storage of traffic audit logsYes
mab for radius based authenticationYes
maximum number of ipv4 static routes500
maximum number of ipv6 static routes500
maximum number of concurrent sessions300000
number of 10 100 1000 2500base t ports4
recommended number of concurrent clients1500
maximum number of devices that can be managed128
number of ospf neighbors on a point to point interface64
maximum number of vlans supported by all lan interfaces128
