BLCSupport
EMCCE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130) FCC SDoC (47 CFR Part 15; Subpart B)
HLCSupport
OSDUp to 10 OSDs
P/NSupport
ROIUp to 8 areas
S/N> 56 dB
WDR120 dB
FlipNormal, Flip vertical, Flip horizontal, 180°
IrisF1.65 to F3.8
ClassDate | Title | Download
DefogDigital defog
PowerDC 24 V±25%, AC 24 V±25%, PoE (IEEE 802.3at)
ClientEZStation, UNV-Link, UNV-Link Pro
SafetyUL (UL 62368-1) CUL (CAN/CSA C22.2 No. 62368-1) CE-LVD (EN IEC 62368-1)
Sensor1/2.8" CMOS
U-codeSupport
Weight5.18 kg (11.42 lb)
Network1 × RJ45 10 M/100 M Base-TX Ethernet
ShutterAuto/Manual, 1 to 1/100000 s
HD Image2026/9/12 3:01:05 | IPC6624SR-X25-VD2_HD_Image_3.png | png | Download
SecurityPassword Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3
Alarm I/O2/1
Audio I/O1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Case TypePT
Datasheet2026/8/3 16:22:40 | UNV IPC6624SR-X25-VD2 4MP X25 Lighthunter IR Intelligent Network PTZ Camera.pdf | English | pdf | Preview | Download
Day/NightIR-cut filter with auto switch (ICR)
Pan Range360° (endless)
Pan Speed0.1°/s to 288°/s
ProtocolsSSH, IGMP, RTP, RTMP, RTCP, IPv4, SSL/TLS, QoS, 802.1x, HTTPS, HTTP, UPnP, NTP, DDNS, DNS, RTSP, DHCP, UDP, TCP, ARP, ICMP, IPv6, SMTP, PPPoE, SNMP
User/HostUp to 32 users. 3 user levels: administrator, common user and operator
Dimensions2026/9/12 3:01:05 | IPC6624SR-X25-VD2_Dimensions_1.png | Download
Frame RateMain Stream Max: 4 MP (2688 × 1520), 30 fps Main Stream Default: 4 MP (2560 × 1440), 25 fps Sub Stream Max: 1080P (1920 × 1080), 30 fps Third Stream Max: D1 (720 × 576), 30 fps Fourth Stream Max: D1 (720 × 576), 30 fps Fifth Stream Max: D1 (720 × 576), 30 fps
ProtectionIP67 (IEC 60529) ; IK10 (IEC62262; Anti-Vandalism Except for the Front Window)
Tilt Range-15° to 90° (auto flip)
Tilt Speed0.1°/s to 288°/s
EnvironmentCE-ROHS (2011/65/EU; (EU) 2015/863) WEEE (2012/19/EU)
Quick Guide2026/7/15 4:10:44 | Quick Guide.pdf | English | pdf | Preview | Download
Serial Port1 × RS485
SuppressionSupport
User Manual2025/12/10 9:40:06 | UNV-Network Camera User Manual.pdf | English | pdf | Preview | Download
Web BrowserPlug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Digital Zoom8X
Edge StorageMicroSD, up to 512 GB
Focal Length4.8 to 120 mm
Optical Zoom25X
Privacy Mask24 areas, up to 8 areas per scene
Reset ButtonSupport
Video StreamFive streams
Auto TrackingUNV Large Model
Home PositionSupport
Preset Patrol16 patrols, up to 64 presets for each patrol
Sampling Rate8 kHz, 16 kHz
Two-way AudioSupport
White BalanceAuto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance
Max Resolution4 MP
NDAA CompliantSupport
Video Bit Rate128 Kbps to 16 Mbps
3D Privacy MaskSupport
Network StorageNAS (NFS)
People CountingSupport people flow counting and crowd density detection
Power InterfaceWires with cold-pressed terminal
General FunctionWatermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output, HTTP authentication
Patrol Stay Time15 s to 1800 s
Surge Protection6 KV
Audio CompressionG.711U, G.711A, AAC-LC
Field of View (D)63.60° to 3.69°
Field of View (H)53.90° to 3.00°
Field of View (V)31.92° to 1.69°
IR On/Off ControlAuto/Manual
Min. IlluminationColor: 0.003 Lux (F1.65, AGC ON), B/W: 0.002 Lux (F1.65, AGC ON), 0 Lux with Light
Number of Presets1024
Power ConsumptionMax. 20.70 W
Video CompressionH.265, H.264, MJPEG, Ultra 265
Exception DetectionObject removed, Object Left Behind
Image StabilizationDIS
Preset Image FreezeSupport
Storage Environment-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Web Client Language22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Working Environment-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Compatible IntegrationSDK, API, ONVIF (Profile S, Profile G, Profile T, Profile M)
DORI Distance (Detect)119.9 m to 2407.5 m (393.5 ft. to 7898.6 ft)
DORI Distance (Observe)48.0 m to 963.0 m (157.4 ft. to 3159.4 ft)
Digital Noise Reduction2D/3D DNR
DORI Distance (Identify)12.0 m to 240.8 m (39.3 ft. to 789.9 ft)
DORI Distance (Recognize)24.0 m to 481.5 m (78.7 ft. to 1579.7 ft)
Frame Rate Recommendation2688 × 1520@30 fps + 1080P@30 fps + D1@30 fps + D1@30 fps + D1@30 fps
Illumination Distance (IR)250 m (820.2 ft)
Smart Intrusion PreventionCross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
Low Illumination CharacteristicsColorHunter with Wise-ISP
