BLCSupport
EMCCE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130) FCC SDoC (47 CFR Part 15; Subpart B)
HLCSupport
OSDUp to 10 OSDs
P/NSupport
ROIUp to 8 areas
WDR120 dB
FlipNormal, Flip vertical, Flip horizontal, 180°
IrisF1.5 to F4.0
ClassDate | Title | Download
DefogDigital defog
PowerDC 24 V±25%, AC 24 V±25%, PoE (IEEE 802.3at)
ClientEZStation, UNV-Link, UNV-Link Pro
SafetyUL (UL 62368-1) CUL (CAN/CSA C22.2 No. 62368-1) CE-LVD (EN IEC 62368-1)
Sensor1/2.8" CMOS
U-codeSupport
Network1 × RJ45 10 M/100 M Base-TX Ethernet
ShutterAuto/Manual, 1 to 1/100000 s
HD Image2026/9/7 11:32:19 | IPC6622SR-X33-VD2_HD_Image_3.png | png | Download
SecurityPassword Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3
Alarm I/O2/1
Audio I/O1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Datasheet2026/6/22 15:10:48 | UNV IPC6622SR-X33-VD2 2MP X33 Lighthunter IR Intelligent Network PTZ Camera.pdf | English | pdf | Preview | Download
Day/NightIR-cut filter with auto switch (ICR)
Pan Range360° (endless)
Pan Speed0.1°/s to 288°/s
ProtocolsSSH, IGMP, RTP, RTMP, RTCP, IPv4, SSL/TLS, QoS, 802.1x, HTTPS, HTTP, UPnP, NTP, DDNS, DNS, RTSP, DHCP, UDP, TCP, ARP, ICMP, IPv6, SMTP, PPPoE, SNMP
User/HostUp to 32 users. 3 user levels: administrator, common user and operator
Dimensions2026/9/7 11:32:19 | IPC6622SR-X33-VD2_Dimensions_1.png | Download
Frame RateMain Stream Max: 1080P (1920 × 1080), 60 fps Main Stream Default: 1080P (1920 × 1080), 25 fps Sub Stream Max: 1080P (1920 × 1080), 60 fps Third Stream Max: D1 (720 × 576), 60 fps Fourth Stream Max: D1 (720 × 576), 60 fps Fifth Stream Max: D1 (720 × 576), 60 fps
ProtectionIP67 (IEC 60529) ; IK10 (IEC62262; Anti-Vandalism Except for the Front Window)
Tilt Range-15° to 90° (auto flip)
Tilt Speed0.1°/s to 288°/s
Quick Guide2026/7/15 4:10:44 | Quick Guide.pdf | English | pdf | Preview | Download
Serial Port1 × RS485
SuppressionSupport
User Manual2025/12/10 9:40:06 | UNV-Network Camera User Manual.pdf | English | pdf | Preview | Download
Web BrowserPlug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Digital Zoom8X
Edge StorageMicroSD, up to 512 GB
Focal Length4.5 to 148.5 mm
Optical Zoom33X
Privacy Mask24 areas, up to 8 areas per scene
Reset ButtonSupport
Route Patrol16 patrols, up to 32 actions for each patrol
Video StreamFive streams
Auto TrackingUNV Large Model
Home PositionSupport
Sampling Rate8 kHz, 16 kHz
Two-way AudioSupport
Max Resolution2 MP
NDAA CompliantSupport
Video Bit Rate128 Kbps to 16 Mbps
3D Privacy MaskSupport
Network StorageNAS (NFS)
People CountingSupport people flow counting and crowd density detection
Power InterfaceWires with cold-pressed terminal
General FunctionWatermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output, HTTP authentication
Patrol Stay Time15 s to 1800 s
Surge Protection6 KV
Audio CompressionG.711U, G.711A
Field of View (D)72.50° to 3.36°
Field of View (H)58.94° to 2.85°
Field of View (V)33.18° to 1.60°
IR On/Off ControlAuto/Manual
Min. IlluminationColor: 0.001 Lux (F1.5, AGC ON), B/W: 0.0005 Lux (F1.5, AGC ON), 0 Lux with Light
Number of Presets1024
Video CompressionH.265, H.264, MJPEG, Ultra 265
Heatwave ReductionSupport
Exception DetectionObject removed, Object Left Behind
Image StabilizationDIS
Preset Image FreezeSupport
Storage Environment-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Web Client Language22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Working Environment-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Compatible IntegrationONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API
DORI Distance (Detect)72.9 m to 2187.9 m (239.3 ft. to 7178.3 ft)
DORI Distance (Observe)29.2 m to 875.2 m (95.7 ft. to 2871.3 ft)
Digital Noise Reduction2D/3D DNR
DORI Distance (Identify)7.3 m to 218.8 m (23.9 ft. to 717.8 ft)
DORI Distance (Recognize)14.6 m to 437.6 m (47.9 ft. to 1435.7 ft)
Frame Rate Recommendation1080P@60 fps + 1080P@60 fps + D1@60fp + D1@60fp + D1@60fp
Illumination Distance (IR)250 m (820.2 ft)
Smart Intrusion PreventionCross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
Low Illumination CharacteristicsColorHunter with Wise-ISP
